D-STAR OPERATION <ADVANCED>

Repeater list

You can store repeater information for quick and simple
communication in up to 1200 repeater memory chan-
nels (Repeater list) in up to 30 Groups.
Entering data into the repeater list is required to use the
DR function.
You can enter four types of frequencies into the repeat-
er list, as shown below:
• DV repeater
• DV simplex
• FM repeater
• FM simplex

D Repeater list contents

The following contents are included in the repeater list:
• TYPE (Frequency type) (p. 7-22)
• NAME (Repeater name) (p. 7-22)
• SUB NAME (Repeater sub name) (p. 7-22)
• CALL SIGN (Repeater call sign and port letter)
(p. 7-22)
• GW CALL SIGN (Gateway repeater's call sign and
port "G") (p. 7-23)
• GROUP (Repeater group) (p. 7-23)
• USE(FROM) (Access repeater use) (p. 7-23)
• FREQUENCY (Access repeater's input frequency)
(p. 7-23)
• DUP (Duplex direction) (p. 7-23)
• OFFSET FREQ (Frequency offset) (p. 7-23)
• MODE (p. 7-23)
• TONE (p. 7-24)
• Repeater Tone (p. 7-24)
• POSITION (Position data accuracy level) (p. 7-24)
• LATITUDE (Latitude of the repeater)
(p. 7-24)
• LONGITUDE (Longitude of the repeater)
(p. 7-24)
• UTC OFFSET (UTC Offset) (p. 7-24)
NOTE: For easy operation, the repeater list is pre-
loaded into your transceiver. However, if you do an
All Reset, the CPU clears all the setting data, the
memory channels and the repeater list.
We recommend that you back up the memory data
to a SD card or save it to a PC using the CS-5100
cloning software
About the repeater list:
The repeater list can be downloaded from the Icom
website.
http://www.icom.co.jp/world/support/download/firm/
index.html
Example: "Hirano" repeater information
7-20
.
