MENU SCREEN

Call Sign items

Call Sign
Call Sign
Sets or views the "UR," "R1," "R2," and "MY" call signs to
use for the DV operation.
When you don't use the DR function in the DV mode,
sets the desired call signs in this screen.
For Simplex operation (DV mode)
"UR" and "MY" call signs can be set.
For Duplex (repeater) operation (DV mode/DR func-
tion)
Only "MY" call sign can be set when using the DR func-
tion.
<To set Duplex (repeater) operation>
Example: Making a gateway CQ call to Inage repeat-
er (JP1YJQ A) from the Hirano repeater
(JP3YHH A), in the DV mode.
• Before starting to set the call sign, set the fre-
quency of your access repeater and duplex di-
rection. (See section 7)
For your reference:
When the DR function is ON, the repeater call sign
can be automatically set. (p. 12-45)
1. Call sign "R1" setting
In the DV mode, touch "R1" for 1 second.
q
Touch "Edit."
w
Touch the keypad to enter the first character.
e
• Alphanumeric characters and symbol ("/") can be en-
tered.
Touch [ ] to move the cursor backwards, or touch
r
[] to move the cursor forwards.
Repeat steps e and r to enter a name of up to 8
t
characters, including a spaces.
After entering, touch [ENT].
y
2. Gateway "R2" setting
Touch "R2."
q
Touch "GW."
w
To manually enter the call sign, touch "R2" for 1 sec-
ond in step q.
About the RPT2 SELECT screen
NOT USED* For local area call
To select the gateway call sign from the
GW
repeater list.
Repeater To select the repeater that has the
name same gateway as the "R1" repeater.
3. Destination "UR" setting
Touch "UR."
q
Touch "Gateway CQ."
w
Touch "11:Japan" (repeater group where your desti-
e
nation repeater is listed).
Touch "Inage."
r
To manually enter the call sign, touch "UR" for 1 sec-
ond in step q.
About the YOUR SELECT screen
To select "CQCQCQ" to make a non-
CQCQCQ
call sign specific call.
To select "Gateway CQ" to make a call
Gateway CQ †
using the repeater list.
To select the destination "UR" call sign
Your Call Sign
using the Your Call Sign memory.
To select the destination "UR" call sign
RX History
using the RX History.
To select the destination "UR" call sign
TX History
using the TX History.
†
Not displayed in the Simplex mode.
12-37
