12
MENU SCREEN
GPS items (Continued)
5. When the caller's TX format is D-PRS Weather
Displays the caller's direction from
Compass*
your position
Latitude Displays the caller's latitude
Longitude Displays the caller's longitude
Displays the grid locator based on
GL the latitude and longitude of the caller
station's position
Displays the caller's distance from
DST
your position
Displays the temperature of the caller
TEMP
station's area
Displays the rainfall of the caller sta-
RAIN
tion's area
Displays the wind direction of the
WIND DIR
caller station's area
Displays the wind speed of the caller
WIND SPD
station's area
Displays the barometric pressure of
BARO
the caller station's area
Displays the humidity of the caller
HUMI
station's area
Displays the caller station's D-PRS
Symbol
symbol
SSID Displays the caller's SSID
Displays the time that the caller
GPS Time Stamp
acquired the weather data.
Displays the caller's call sign (with
Call sign
SSID)
[MEM] screen (GPS memory alarm position)
Displays GPS Memory channel's di-
Compass*
rection from your position
Displays GPS Memory channel's lati-
Latitude
tude
Displays GPS Memory channel's lon-
Longitude
gitude
Displays the grid locator based on the
GL latitude and longitude of GPS Memo-
ry channel's.
Displays GPS Memory channel's dis-
DST
tance from your position
Displays the selected GPS memory
GPS memory name*
name
[ALM] screen (GPS alarm position)
Displays GPS Alarm area's direction
Compass*
from your position
Latitude Displays GPS Alarm area's latitude
Longitude Displays GPS Alarm area's longitude
Displays the grid locator based on the
GL latitude and longitude of GPS Alarm
area's.
Displays GPS Alarm area's distance
DST
from your position
Displays "RX," GPS memory group
GPS Alarm* name or GPS memory name speci-
fied for the GPS alarm function.
*These items can be selected in the Quick Menu screen.

GPS Memory

GPS > GPS Memory
The transceiver has 200 GPS memory channels to
store the received position data, or often-used position
data, along with an alphanumeric channel name.
The channels can be divided into the "(No Group)"
group and each memory group (A to Z) for easy mem-
ory management.
The display of the GPS memory
(No Group)
A to Z : Group Name
GPS memory groups (A-Z)
GROUP NAME
The GPS memory group name can be edited in the
Quick Menu screen. (p. 8-33)
GPS memory channels
NAME
DATE
TIME
LATITUDE
LONGITUDE
ALTITUDE
GROUP
When you store the received position data in the
"GPS Positon" screen, the received station's call sign
is used as the GPS memory name.
GPS memory contents, such as the GPS memory
name, can be edited in the Quick Menu screen. (pp.
8-29 to 8-32)
12-34
GPS memories not assigned to any
group.
GPS memories assigned to the se-
lected group.
GPS memory group name
(Up to 16 alphanumeric characters)
GPS memory channel name
(Up to 16 alphanumeric characters)
Stored date
Stored time
Stored location (latitude)
Stored location (longitude)
Stored altitude
The group letter and the name of the
group
