OTHER FUNCTIONS
Remote jack (CI-V) information (Continued)
• GPS/D-PRS data— Weather
Command: 20 0301, 20 0302
q–o !0 !1
0 3 X X • • • X X X X X X X X
Data number
q–o: Call sign/SSID
*9 ASCII characters (A–Z, 0–9, /, -, space)
!0 , !1 : Symbol
*2 ASCII characters (00h–EFh)
!2 – !6 : Latitude (ddºmm.mmm format)
!7 – @2 : Longitude (dddºmm.mmm format)
@3 – @9 : Date (UTC: yyyymmddHHMMSS)
* y: Year, m: Month, d: Day, H: Hour, M: Minute,
S: Second
• GPS/D-PRS message
Command: 20 0401, 20 0402
q–o
X X • • • X X
q–o: Call sign/SSID
*9 ASCII characters (A–Z, 0–9, /, -, space)
!0 – %2 : Message
*Up to 43 ASCII characters (00h–EFh)
• MY position data
Command: 23 00
X X
q–t: Latitude (ddºmm.mmm format)
y–!1 : Longitude (dddºmm.mmm format)
!2 – !5 : Altitude (0.1 meter steps)
!6 , !7 : Course (1 degree steps)
• Manually input position data
Command: 23 02
q–t
X X X X X X
• • •
q–t: Latitude (ddºmm.mmm format)
y–!1 : Longitude (dddºmm.mmm format)
!2 – !5 : Altitude (0.1 meter steps)
!2 – !6 !7 – @2
• • • X X X X • • • X X X X
!0 – %2
X X • • • X X
Varible
q–t y–!1
X X X X X X X X
• • • • • •
!2 – !5
y–!1
X X X X X X
• • • • • •
@3 – @9
#0 #1 #2 #3 #4 #5
• • • X X X X X X X X X X X X
#0 , #1 : Wind direction (1 degree steps)
#2 , #3 : Wind speed (0.1 m/s steps)
#4 , #5 : Gust speed (0.1 m/s steps)
#6 – #7 : Temperature (0.1ç steps)
: Temperature (0=+ degree, 1=– degree)
#8
#9 , $0 : Rainfall (0.1 mm steps)
$1 , $2 : Rainfall (24 hours) (0.1 mm steps)
$3 , $4 : Rainfall (Midnight) (0.1 mm steps)
$5 , $6 : Humidity (1% steps)
$7 – $9 : Barometric pressure (0.1 hPa steps)
• DV TX data, DV RX data (transceive)
Command: 22 00, 22 01 01
X X
q–#0 : Tx, data Rx data (Up to 30 Byte)
*" FA" to "FF" are entered after converted to "FF 0A"
to "FF 0F" automatically. Up to 60 Byte data can
be entered in this case.
!2 – !5 !8 – @0
!6 !7
X X X X X X X X
• • • • • •
!8 – @0 : Speed (0.1 km/h steps)
@1 – @7 : Date (UTC: yyyymmddHHMMSS)
* y: Year, m: Month, d: Day, H: Hour, M: Minute,
S: Second
13-22
#6 – #8
#9 $0 $1
X X X X • • • X X X X X X X X
$2 $3 $4 $5 $6
X X X X X X X X X X X X
q–#0
X X
• • • • • • • • • • • • • • • •
Varible
@1 – @7
X X X X X X
• • •
$7 – $9
X X
• • •
