OTHER FUNCTIONS
Remote jack (CI-V) information (Continued)
• DV TX call signs setting (24 characters)
Command: 1F 01
Set "UR," "R1" and "R2" call signs of 8 characters
(fixed).
q–i
X X • • • X X X X
q–i: UR (Destination) call sign setting (8 charac-
ters)
o–!6 : R1 (Access/Area repeater) call sign setting (8
characters)
!7 – @4 : R2 (Link/Gateway repeater) call sign setting
(8 characters)
• Character's code of the call sign
Character
0–9
A–Z
(Space)
/
• DV TX message setting
Command: 1F 02
Set the transmit message of up to 20 characters.
"FF" stops sending or reading messages.
Character ASCII code
A–Z 41–5A
0–9 30–39
! 21
$ 24
& 26
? 3F
' 27
^ 5E
– 2D
/ 2F
, 2C
; 3B
< 3C
( 28
[ 5B
{ 7B
¦ 7C
¯ 7E
!7 – @4
o–!6
• • • X X X X • • • X X
ASCII code
30–39
41–5A
20
2F
Character ASCII code
a–z 61–7A
Space 20
# 23
% 25
\ 5C
" 22
` 60
+ 2B
2A
Q
. 2E
: 3A
= 3D
> 3E
) 29
] 5D
} 7D
_ 5F
@ 40
• DV RX call sign data
Command: 20 0001, 20 0002
q Header flag data (First byte)
Data
bit7 (0 :Fixed)
bit6 (0 :Fixed)
bit5 (0 :Fixed)
bit4 0/1
bit3 0/1
bit2 0/1
bit1 0/1
bit0 0/1
w Header flag data (Second byte)
Data
bit2 bit1 bit0
1 1 1
1 1 0
1 0 1
1 0 0
0 1 1
0 1 0
0 0 1
0 0 0
e–!0 : Call sign of the caller station (8 characters;
fixed)
!1 – !4 : Note of the caller station (4 characters; fixed)
!5 – @2 : Call sign of the called station (8 characters;
fixed)
@3 – #0 : Call sign of the access/area repeater (R1) (8
characters; fixed)
#1 – #8 : Call sign of the link/gateway repeater (R2) (8
characters; fixed)
• "FF" stands for no call sign receiving after turning ON the
transceiver.
13-19
Description
—
0=Voice, 1=Data
0=Direct, 1=Through repeater
0=No Break-in, 1=Break-in
0=Data, 1=Control
0=Normal, 1=EMR
Description
Repeater control
Send auto acknowledge
(Not used)
Request to re-transmit
Send acknowledge
Receive no reply
Repeater disabled
NULL
