12
MENU SCREEN

RX History items

RX History
RX History
When a call is received in the DV mode, the call infor-
mation such as the caller station's call sign, the repeat-
er's call sign, and so on, are stored in this screen.
Up to 50 records can be stored.
• Even if the transceiver power is turned OFF, the stored
records are not deleted.
Touch [∫] or [√] one or more times to confirm the RX
record contents.
Contents of the RX History Top screen
RX01–RX50 RX history number
Displays the call sign of the caller station
CALLER* 1 and any note programmed after the call
sign.
Displays the call sign of the called sta-
1
CALLED*
tion.
Displays any message included in the re-
MESSAGE
ceived call, if programmed.
Displays the call sign of the repeater you
RXRPT2* 1
received the call from.
Displays the frequency the call was re-
ceived.
FREQUENCY
( This item appears only when the sim-
plex call is received.)
Displays the date and time the call was
RX TIME
received.
Appears when a call is received through
GW
the internet.
Appears when position data is included.
GPS
(NMEA or Mobile/Base station)
Appears when the object's data is in-
OJB
cluded.
Appears when the item's data is includ-
ITEM
ed.
Appears when the weather station's data
WX
is included.
Appears when an uplink signal is re-
(UP)
ceived.
RX>CS Touch to capture the call sign.
DETAIL Touch to display the detail screen.
Displays the caller's direction from your
Compass* 2
position.
Displays the caller's distance from your
Distance
position.
Symbol Displays the caller's symbol.
* 1 These items can be switched to the Name display.
* 2 If you have no position data, these items are not displayed.
3
* These items show the name under the call sign, if pro-
grammed.
* 4 "FREQUENCY" appears instead of these items when the
call was not through a repeater (Simplex call), to show the
frequency that was used.
<The contents of the detail screen>
The contents of the detail screen differ, whether the
position data is included in the received data or not.
The position data that is included in the received data
can be divided into five categories. Depending on the
caller's TX mode or TX format, the displayed items and
these meanings differ.
The following lists show the items for each category.
• Nothing is displayed when no position data is received.
Common items
Displays the call sign of the caller station
3
CALLER* and any note programmed after the call
sign.
Displays the call sign of the called sta-
3
CALLED*
tion.
Displays the call sign of the repeater that
was accessed by the caller station.
If it was a call through a gateway and the
RXRPT1* 3, * 4
internet, this item displays the gateway
repeater call sign of your local area re-
peater.
Displays the call sign of the repeater you
RXRPT2* 3, 4
*
received the call from.
Displays any message included in the re-
RX MESSAGE
ceived call, if programmed.
Displays the date and time the call was
RX TIME
received.
1. When the caller's TX mode is NMEA
Displays the caller's direction from your
2
Compass*
position
Latitude Displays the caller's latitude
Longitude Displays the caller's longitude
Displays the grid locator based on the
GL latitude and longitude of the caller's po-
sition.
ALT Displays the caller's altitude
Displays the caller's distance from your
DIST* 2
position
COURSE Displays the caller's direction over ground
SPEED Displays the caller's speed
Displays the time that the caller acquired
GPS Time Stamp
the position data.
Call sign Displays the caller's call sign
Displays the GPS message included in
GPS MESSAGE
the position data of the received call.
12-38
