12
MENU SCREEN
Menu items and Default settings (Continued)
NOTE: The default settings shown in bold letters below are for the USA version.
The default settings may differ, depending on your transceiver version.
1
DV Auto Reply*
Voice TX
Record* 1
TX Set
Repeat Time
TX Monitor
<<TX>>* 1
GPS
GPS Set
GPS Select
Manual Position
GPS Out (To DATA Jack)
GPS TX Mode
OFF
D-PRS
Unproto Address
TX Format
Position
Symbol
SSID
Comment
Time Stamp
Altitude
Data Extension
Power
Height
Gain
Directivity
Object
Object Name
Data Type
Symbol
Comment
Position
Data Extension
Course
Speed
Power
Height
Gain
Be sure to insert the SD card into the transceiver before selecting these items.
* 1
The unit may differ, depending on the "Display Unit" settings. (p. 12-59)
* 2
Set microphone voice recording options.
T1~T4
1sec~5sec~15sec
OFF or ON
T1~T4, Repeat TX
Set the GPS options.
OFF, Internal GPS or Manual
OFF or ON
API510,DSTAR*
1:Car, 2:Van, 3:Truck or 4:House QTH (VHF) Selects a desired D-PRS Symbol to transmit.
- - -, (-0), -1~-15 or -A~-Z
OFF, DHM or HMS
OFF or ON
OFF, Course/Speed or
Power/Height/Gain/Directivity
0W, 1W, 4W, 9W, 16W, 25W, 36W,
49W, 64W or 81W
10ft, 20ft, 40ft, 80ft, 160ft, 320ft,
640ft, 1280ft, 2560ft, 5120ft*
0dB~9dB
Omni, 45°NE, 90°E, 135°SE, 180°S,
225°SW, 270°W, 315°NW, 360°N
Live Object, Killed Object
Radio
OFF, Course/Speed or
Power/Height/Gain/Directivity
0°~360°
0mph~1150mph* 2
0W, 1W, 4W, 9W, 16W, 25W, 36W,
49W, 64W or 81W
10ft, 20ft, 40ft, 80ft, 160ft, 320ft,
640ft, 1280ft, 2560ft, 5120ft*
0dB~9dB
12-4
Records a voice audio to use the Auto Reply function
in the DV mode.
Starts recording the microphone audio.
Sets the repeat interval. The transceiver repeatedly
transmits the recorded voice audio at this interval.
The TX Monitor function outputs the TX voice audio
from the speaker during voice transmission.
The transceiver transmits the recorded voice audio.
Selects the position data source that the transceiver
uses for its position data.
Manually enter your current position.
Selects to output the GPS information to the [DATA]
jack
Turns OFF the GPS TX function.
Enters an unproto address, or keep the default.
Selects the APRS
Enters a comment to transmit.
Selects a format to transmit the current UTC time as
a time stamp.
Turns the altitude transmit option ON or OFF.
Selects whether to transmit the course/speed data,
power/height/gain/directivity data or not.
Selects the TX power level information to send when
using as a base station.
Selects the height information to send when using as
2 a base station.
Selects the antenna gain information to send when
using as a base station.
Selects the antenna directivity information to send
when using as a base station.
Enters a object station name to transmit.
Selects a object station's status to transmit.
Selects a object station's symbol to transmit.
Enters a object station's comment to transmit.
Sets a object station's position data to transmit.
Selects whether to transmit the object station's course/
speed data, power/height/gain/directivity data or not.
Sets a object station's course to transmit.
Sets a object station's speed to transmit.
Selects a object station's TX power level information
to transmit.
Selects the height information of the object station
2 to transmit.
Selects the antenna gain information of the object
station to transmit.
®
call sign SSID.
