7
D-STAR OPERATION <ADVANCED>

EMR communication

The EMR (Enhanced Monitor Request) communication
function can be used in only the DV mode. Using the
EMR function, no call sign setting is necessary.
All transceivers that receive an EMR signal automati-
cally open their squelch to receive the signal.
When an EMR signal is received, the audio (voice) will
be heard at the specified level, even if the volume set-
ting level is set to the minimum level, or the digital call
sign/digital code squelch is in use. (Default: OFF)
NOTE: The EMR communication function is auto-
matically turned OFF when the transceiver is turned
OFF.
Example: To transmit from the "Hirano" repeater using
the EMR function.
Touch [MENU].
q
Touch "EMR."
w
(DV Set > EMR)
• If the item is not displayed, touch [∫] or [√] one or more
times to select another page.
Touch "ON."
e
Touch [MENU].
r
• Closes the Menu screen.
• "EMR" appears.
Appears
t Push [PTT] to transmit.
• The LED1 on the microphone lights red.
• "EMR" blinks on a station that receives the EMR signal.
The audio (voice) will be heard at the specified level, or
the [VOL] control level, whichever is higher.
y Release [PTT] to receive.
To cancel the EMR function, select "OFF" in step
u
as described above, or turn OFF the power.

D Adjusting the EMR AF level

The audio output level when an EMR signal is received
is adjustable between 0 and 32.
When an EMR signal is received, the audio will be
heard at the preset level, or the [VOL] control level,
whichever is higher.
To disable the setting, set it to
Touch [MENU].
q
Touch "EMR AF Level."
w
(DV Set > EMR AF Level)
• If the item is not displayed, touch [∫] or [√] one or more
times to select another page.
Touch [+] or [–] one or more times to adjust the EMR
e
audio output level between 0 (minimum) and 32
(maximum) in single digit steps. (Default: 19)
Touch [MENU].
r
• Closes the Menu screen.
e,
7-9
"0."
