12
MENU SCREEN
RX History items (Continued)
2. When the caller's TX format is D-PRS Position
(Mobie station)
Displays the caller's direction from your
Compass*
position
Latitude Displays the caller's latitude
Longitude Displays the caller's longitude
Displays the grid locator based on the
GL latitude and longitude of the caller's po-
sition.
ALT Displays the caller's altitude
Displays the caller's distance from your
DIST*
position
COURSE Displays the caller's direction over ground
SPEED Displays the caller's speed
Displays the time that the caller acquired
GPS Time Stamp
the position data.
Call sign Displays the caller's call sign (with SSID)
Symbol Displays the caller's D-PRS symbol
Displays the GPS message included in
GPS MESSAGE
the position data of the received call.
3. When the caller's TX format is D-PRS Position
(Base station)
Displays the caller's direction from your
Compass*
position
Latitude Displays the caller's latitude
Longitude Displays the caller's longitude
Displays the grid locator based on the
GL latitude and longitude of the caller's po-
sition.
ALT Displays the caller's altitude
Displays the caller's distance from your
DIST*
position
POWER Displays the caller's TX power level
HEIGHT Displays the height of caller's antenna
GAIN Displays the gain of caller's antenna
Displays the direction that the caller's an-
DIRECT
tenna was pointing
Displays the time that the caller acquired
GPS Time Stamp
the position data.
Call sign Displays the caller's call sign (with SSID)
Symbol Displays the caller's D-PRS symbol
Shows the GPS message included in the
GPS MESSAGE
position data of the received call.
4. When the caller's TX format is D-PRS Object/Item
Displays the Object/Item station's direc-
Compass*
tion from your position
Displays the Object/Item station's lati-
Latitude
tude
Displays the Object/Item station's longi-
Longitude
tude
Displays the grid locator based on the
GL latitude and longitude of the Object/Item
station's position.
Displays the Object/Item station's alti-
ALT
tude
Displays the Object/Item station's dis-
DIST*
tance from your position
Displays the Object/Item station's direc-
COURSE
tion over ground
SPEED Displays the Object/Item station's speed
Displays the Object/Item station's TX
POWER
power level
Displays the height of Object/Item sta-
HEIGHT
tion's antenna
Displays the gain of Object/Item station's
GAIN
antenna
Displays the direction that the Object/
DIRECT
Item station's antenna was pointing
Displays the time that the caller sent the
GPS Time Stamp
Object station's data.
Call sign Displays the caller's call sign (with SSID)
Displays the Object/Item station's D-PRS
Symbol
symbol
Displays "KILLED" when the object or
Status
Item station is disabled.
Displays the GPS message included in
GPS MESSAGE
the position data of the received call.
*If you have no position data, these items are not displayed.
12-39
