8
GPS OPERATION
Checking your GPS position (Continued)
D TX format: D-PRS Weather
The following items are displayed when the caller's TX
format is D-PRS Weather.
Displays the caller's direction from
Compass
your position
Latitude Displays the caller's latitude
Longitude Displays the caller's longitude
Displays the grid locator based on
GL the latitude and longitude of the caller
station's position
Displays the caller's distance from
DST
your position
Displays the temperature of the caller
TEMP
station's area
Displays the rainfall of the caller sta-
RAIN
tion's area
Displays the wind direction of the
WIND DIR
caller station's area
Displays the wind speed of the caller
WIND SPD
station's area
Displays the barometric pressure of
BARO
the caller station's area
Displays the humidity of the caller
HUMI
station's area
Displays the caller station's D-PRS
Symbol
symbol
SSID Displays the caller's SSID
Displays the time that the caller
GPS Time Stamp
acquired the weather data.
Displays the caller's call sign (with
Call sign
SSID)
D TX mode: NMEA
The following items are displayed when the caller's TX
mode is NMEA.
Compass*
Latitude
Longitude
GL
ALT
DST
COURSE
SPEED
GPS Time Stamp
Call sign
8-9
Displays the caller's direction from
your position.
Displays the caller's latitude
Displays the caller's longitude
Displays the grid locator based on the
latitude and longitude of the caller's
position.
Displays the caller's altitude
Displays the caller's distance from
your position
Displays the caller's direction over
ground
Displays the caller's speed
Displays the time that the caller
acquired the position data.
Displays the caller's call sign
