12
MENU SCREEN

Menu items and Default settings

NOTE: The default settings shown in bold letters below are for the USA version.
The default settings may differ, depending on your transceiver version.
DUP/TONE...
Offset Freq
Repeater Tone
TSQL Freq
Tone Burst
DTCS Code
DTCS Polarity
Digital Code
Manage Memory
Memory CH
Call CH
Scan
Pause Timer
Resume Timer
Temporary Skip Timer
Program Skip
Bank Link
Program Scan Edge
Program Link
See page 12-15 for details of the preset values.
Voice Memo
QSO Recorder
<<REC Start>>* 3
3
Play Files*
Recorder Set
REC Mode
RX REC Condition
File Split
PTT Auto REC
Player Set
Skip Time
1
* The default value may differ, depending on the frequency band (selected as the MAIN band before entering the Menu screen)
and the transceiver version.
2 The default value may differ, depending on the transceiver version.
*
3 Be sure to insert the SD card into the transceiver before selecting these items.
*
Settings to access repeaters.
1
0.000~0.600.00* ~59.995 MHz
67.0~88.5~254.1 Hz
67.0~88.5~254.1 Hz
OFF or ON
023~754
Both N, TN-RR, TR-RN or Both R
00~99
Manage your Memory or Call channel data.
ALL, A~Z
2
C0/C1(144):146.010 FM*
C0/C1(430):440.000 FM* 2
Set scan options.
2sec~10sec~20sec or HOLD
0sec~2sec~5sec or HOLD
5min, 10min or 15min
OFF or ON
A: ✔ ~Z: ✔
00~24
Set the TX/RX voice recording options.
PLAY FILES
TX&RX or RX Only
Always or Squelch Auto
OFF or ON
OFF or ON
3sec, 5sec, 10sec or 30sec
12-3
Sets the frequency offset for duplex (repeater) op-
eration.
Selects a tone frequency used to access the repeat-
ers.
Selects a tone frequency for the Tone squelch or the
pocket beep function.
Turns the Tone Burst function ON or OFF.
This function is used to suppress the squelch tail noise
heard from the transceiver's speaker.
Selects a DTCS (both encoder/decoder) code for
DTCS squelch or the pocket beep function.
Selects the DTCS polarity for the DTCS squelch or
the pocket beep function.
Selects a digital code for the Digital Code squelch
function.
Manages for the Memory channels.
Manages for the Call channels.
Selects the scan pause time. When receiving signals,
the scan pauses according to the scan pause timer.
Selects the scan resume time from a pause after the
received signal disappears.
Selects the Temporary Skip Time. When the time is
set, specified frequencies are skipped for this period
during a scan.
Turns the Program Skip Scan function ON or OFF for
a VFO mode scan.
Selects banks to be scanned during a Bank Link
Scan.
Sets the frequency ranges for the program scan.
Sets the link function for the program scan edge
channels.
Starts recording the received signal audio.
Plays or deletes the recorded audio.
Selects to record the TX audio or not.
Selects whether or not the squelch status affects the
RX voice audio recording.
Selects whether or not to automatically create a new
file if transmission and reception, or squelch status
(open and close) is switched.
Turns the PTT Automatic Recording function ON or
OFF.
Sets the Skip time to rewind or forward the recorded
audio when you push the fast-rewind or fast-forward
key during playback.
