14
OPTIONS
Options
HM-154
hand microphone
MBA-2
controller bracket
• OPC-589
mic adaptor cable
Allows you to connect an 8-pin plug microphone.
• OPC-837
controller cable
Cable length: 3.5 m (11.4 ft)
• OPC-440
mic extenstion cable
Cable length: 5.0 m (16.4 ft)
• OPC-647
mic extenstion cable
Cable length: 2.5 m (8.2 ft)
• CS-5100
cloning software
Free download software (contained in the CD)
• RS-MS1A
Android ®
application
Free download software
• OPC-1529R
data communication cable
RS-232C type
Allows low-speed data communication in the DV mode
and data cloning operation with the CS-5100.
• OPC-2218LU*
data communication cable
USB type
Allows low-speed data communication in the DV mode
and data cloning operation with the CS-5100.
• OPC-478UC*
cloning cable
USB type
Allows data cloning operation with the CS-5100.
* The OPC-478UC and OPC-2218LU cannot be used with the
Windows ® 8.1. (As of March 2014)
HM-207
-
remote control
microphone
MBF-1
mounting base
(for installing the MBA-2)
SP-30
external speaker
Cable length: 2.8 m (9.1 ft)
UT-133
Bluetooth ®
unit
• OPC-1156
controller extension cable
Cable length: 3.5 m (11.4 ft)
• CT-17 -
ci v level converter unit
For remote transceiver control using a personal com-
puter equipped with an RS-232C port. You can change
frequencies, operating mode, memory channels, and
so on with your computer.
Approved Icom optional equipment is designed for
optimal performance when used with an Icom trans-
ceiver.
Icom is not responsible for the destruction or damage
to an Icom transceiver in the event the Icom transceiv-
er is used with equipment that is not manufactured or
approved by Icom.
14-2
SP-35/SP-35L
external speaker
For mobile operation
Cable length
SP-35 : 2 m (6.5 ft)
SP-35L : 6 m (19.7 ft)
VS-3
Bluetooth ®
headset
