12
MENU SCREEN
Display items (Continued)
RX Position Display
Display > RX Position Display
Select whether or not to display the caller's position in
a dialog when the signal received in the DV mode con-
tains a caller station's position.
• OFF: Does not display the caller's position.
• ON (Main/Sub): Displays the caller's position.
• ON (Main Only):Displays the caller's position, re-
ceived in only the MAIN band.
You can set the display time period in the "RX Posi-
tion Display Timer" item.
RX Position Display Timer
Display > RX Position Display Timer
Set the display time period for the caller's position.
• 5/10/15/30sec: Displays the caller's position for this
set period.
• Hold: Displays the caller's position until you
operate the transceiver.
Reply Position Display
Display > Reply Position Display
Select whether or not to display the caller's position in
a dialog when the Auto Reply signal contains a caller
station's position.
• OFF: Does not display the caller's position.
• ON: Displays the caller's position.
TX Call Sign
Display > TX Call Sign
Select whether or not to display your own or the desti-
nation call sign while transmitting in the DV mode.
• OFF: Does not display any call sign.
• Your Call Sign: Displays and scrolls the destination's
call sign.
When the destination's call sign and
name are entered in your memory, the
transceiver displays the name after
the call sign in any DV mode except
when using the DR function.
• My Call Sign: Displays and scrolls your own call
sign.
(Default: ON (Main/Sub))
(Default: 10sec)
(Default: ON)
(Default: Your Call Sign)
Scroll Speed
Display > Scroll Speed
This item sets the scrolling speed of the message, call
sign, or other text, that is displayed on the screen.
• Slow:The scroll speed is slow.
• Fast: The scroll speed is fast.
Opening Message
Display > Opening Message
Select whether or not to display the opening message
at power ON.
• OFF: Opening message is not displayed.
• ON: Icom logo, MY call sign, the product model ("ID-
5100A" or "ID-5100E")* are displayed.
*Depending on the version.
Voltage (Power ON)
Display > Voltage (Power ON)
Select whether or not to display the voltage of the ex-
ternal DC power source at power ON.
• OFF: Does not display the voltage of the external DC
power source at power ON.
• ON: Displays the voltage of the external DC power
source at power ON.
NOTE: When the voltage of the external DC power
source is over 17.0 V, "Over Voltage" is displayed and
disconnect the DC power source immediately.
Latitude/Longitude
Display > Display Unit > Latitude/Longitude
Select either the ddd ºmm.mm' or ddd ºmm'ss'' format
to display the position.
Altitude/Distance
Display > Display Unit > Altitude/Distance
Select either the meter or feet/mile format to display the
distance and altitude.
* The default setting may differ, depending on the transceiv-
er's version.
12-58
(Default: Fast)
(Default: ON)
(Default: ON)
(Default: ddd ºmm.mm')
(Default: feet/mile*)
