12
MENU SCREEN
QSO/RX Log items (Continued)
The log contents are shown below:
Contents Example
TX/RX TX
Date 4/1/2014
13:51:48
Frequency 438.010000 438.010000 Operating frequencies
Mode DV
My Latitude 34.764667
My Longitude 135.375333 135.375333 Your longitude (unit: degree) (+: East longitude, –: West longitude)
My Altitude 50.5
RF Power Low
S-meter (Blank)
RPT Call Sign JP3YHJ A
TX Call Sign CQCQCQ
RX Call Sign (Blank)
RX Latitude (Blank)
RX Longitude (Blank)
RX Altitude (Blank)
RX Transmission and reception
4/1/2014 Date and time the call was started.
13:51:48
( When Duplex is set, the RX frequency is displayed.)
DV Operating mode (AM/AM-N/FM/FM-N/DV)
34.764667 Your latitude (unit: degree) (+: North latitude, –: South latitude)
50.5 Your altitude (unit: m) Records to one decimal place.
(Blank) TX output power level
S0 The relative signal strength of the receive signal (in twelve levels)
JP3YHJ A Repeater call sign (DV mode only)
(Blank) TX Call sign (DV mode only)
JA3YUA A/ RX Call sign (DV mode only)
ID-5100
34.764667 Caller's latitude, if sent. (unit: degree) (+: North latitude, –: South latitude)
Records only when you receive in the DV mode.
135.375333 Caller's longitude, if sent. (unit: degree) (+: East longitude, –: West longitude)
Records only when you receive in the DV mode.
30.5 Caller's altitude, if sent. (unit: m)
Records only when you receive in the DV mode.
Descriptions
12-50
