Web Manager for Regular Users
The form shows separate entries for each serial port configured for power
management, a name for the configured serial port if one is defined by the
administrator, and the number of IPDUs connected. The matrix displays a line
item for each outlet you are authorized to manage.
The authorized user can do the following for any listed outlet:
•
•
•
•
•
The following table describe the corresponding buttons to do the above
operations:
Button
Table 3-4: Regular User > Outlet Management Buttons
58
Edit the outlet name.
Enter a name to identify the server or device plugged into the outlet.
Edit the power up interval.
The power up interval is the time interval (in seconds) that the system
waits between turning on the currently-selected outlet and the next outlet.
The default is set at 30 seconds.
Cycle - Turn power briefly off and on again.
Turn the power On/Off to the outlet.
Lock or unlock the outlet to prevent accidental changes to the power state.
Purpose
Opens a dialog box to
Edit an Outlet name, and the
Power Up Interval.
Turn power briefly off and then on again.
Turn power On/Off.
Lock or unlock the outlet.
