Appendix A: Technical Specifications - Black Box Advanced Console Server User Manual

Appendix A
Technical Specifications
The following table lists the Advanced Console Server hardware
specifications
CPU
Memory
Interfaces
Power
Operating Temperature
Storage Temperature
Humidity
Dimensions
MPC855T (PowerPC Dual-CPU)
128MB DIMM SDRAM / 16MB CompactFlash
1 Ethernet 10/100BT on RJ45
1 RS232 Console on RJ45
RS232 Serial Ports on RJ45
PCMCIA slots supporting: Secondary Ethernet, Wireless networking,
CDMA, GPRS, GSM, V.90 modems, ISDN.
Internal 100-240VAC, 50/60 Hz†
Optional Dual entry, redundant power supplies†
† -48VDC option available
50°F to 112°F (10°C to 44°C)
-40°F to 185°F (-40°C to 85°C)
5% to 90% non-condensating
CS1: 6.3 x 4.0 x 1.5 in (16 x 10 x 3.8 cm)
CS 4-48: 17 x 8.5 x 1.75 in (43.18 x 21.59 x 4.45 cm)
