Configuring the CS in Expert Mode
These forms are identified by their tabs. Select the tab to access the desired
form.
Left Menu
Wizard/Expert

Figure 6-1: Expert Mode Screen Elements

Note: Procedures in this manual use shortcuts to tell how to get to Web Manager
forms. For example, a step telling the user to access the "Outlets Manager"
form use this convention, "In Expert mode, go to Applications> IPDU Power
Mgmt.>Outlets Manager"
106
Top Menu
Tabs
Form Area
Command buttons
