Network Menu & Forms

To Configure a Modem PCMCIA Card

1. Install the modem card and select "Modem" from the pull-down menu on
2. To enable PPP, do the following steps:
3. To enable call back, do the following:
4. Click OK.
5. Click "apply changes."

Configuring an ISDN PCMCIA Card

You can use the "PCMCIA Management" form under "Network" to enable
users to connect to the CS through an ISDN PCMCIA card.
When you select ISDN from the pull-down menu, the dialog box shown in the
following figure appears.
164
the PCMCIA Management form.
a. Check the PPP checkbox.
b. The "Local IP and the "Remote IP" fields, and the "Call Back" check
box appear on the Slot dialog box.
c. Enter an IP address in the "Local IP" field, if desired.
By default, the IP address of the CS is used. Only change the IP
address if you have a specific reason to do so.
d. In the "Remote IP" field, specify the IP address to assign to the other
end of the PPP connection, if desired.
By default, the IP address 10.0.0.1 is assigned. Only change the IP
address if you have a specific reason to do so.
a. Check the "Call Back" check box.
The Phone Number field appears on the Slot dialog box.
b. Enter a number to use to call back the modem.
