Black Box Advanced Console Server User Manual page 184

Network Menu & Forms
Table 8-2: Expert > Host Settings Form Fields
Filed Name
Console Banner
Primary IP
Secondary IP
Network Mask
Secondary Network
Mask
MTU
DNS Server
Secondary DNS
Server
Domain Name
Gateway IP
154
Field Definition
A text string designed to appear on the
console upon logging into and exiting from
a port as a way to verify or identify the
particular port connection.
IP address of the CS unit.
The secondary IP address of the CS unit. By
configuring a second IP address, the unit
will be available for more than one network.
The 32-bit number used to group IP
addresses together or to indicate the range
of IP addresses for a subnet.
Optional.
Maximum Transmission Unit used by the
TCP protocol.
Address of the Domain Name Server.
Address of the backup Domain Name
Server.
The name that identifies the domain, for
example, domainname.com.
The IP address to the gateway on the subnet.
