Table 8-11: Expert > Fields and Menu Options for SNMP Configuration
Field or Menu Option
SysContact
SysLocation
Community
Source
OID
Permission
User Name and
Password
Clicking the "Add" or "Edit" buttons under "SNMPv1/SNMPv2
Configuration" brings up the "New/Mod SNMP v1 v2 Configuration" dialog
box, as shown in the following figure.
BLACK BOX® CS Installation, Administration, and User's Guide
Description
The email address of the CS's administrator, for example,
support@bb.com.
The physical location of the CS.
SNMP v1 and v2 only. A Community defines an access
environment. The type of access is classified under
"Permission": either read only or read write. The most common
community is "public". Take caution in using a "public"
community name as it is commonly known. By default, the
"public" community cannot access SNMP information on the
CS.
SNMP v1 and v2 only. Valid entries are "default" or a subnet
address, for example, 193.168.44.0/24.
Object Identifier. Each managed object has a unique identifier.
"Read Only" access to the entire MIB (Management
Information Base) except for SNMP configuration objects.
"Read/Write" access to the entire MIB except for SNMP
configuration objects.
SNMP v3 only.
Network
183
