Ports Menu & Forms
Field Name
First Local TCP Port No.
Remote IP
First Remote TCP Port
Number
Protocol
Once you have configured the "Slave" CS unit and defined the cluster
parameters, the slave serial ports and the connected devices are accessible
from the master CS unit under Applications > Connect > Serial pull-down
menu as shown in the following figure.
284
Definition
The first TCP port number for the
slave. For example, if the master unit
has 16 ports, the allocated TCP port
numbers to the master are 7001-7016.
The "First Local TCP Port No." is
then 7017. This is a virtual TCP port
number.
The IP address of the slave.
The first TCP port number of the
slave. The default is 7001.
The communication protocol used by the
The options are Telnet or SSH.
slave.
