To Configure A Trigger For Email Notification For Serial Ports - Black Box Advanced Console Server User Manual

Field Name
[untitled dropdown
field]
To/From/Subject/
Body
SMTP Server IP
SMTP Port

To Configure a Trigger for Email Notification for Serial Ports

1. Go to Administration > Notifications in Expert mode, and select Email
2. Specify the event you want to trigger a notification in the "Alarm Trigger"
3. If you need to edit an existing notification select it from the drop-down
4. Enter or change the recipient for the notification email in the "To" field.
5. Enter or change the sender email address in the "From" field.
6. Enter or change the subject in the "Subject" field.
7. Enter or edit the text message in the "Body" field.
8. Enter or change the SMTP server's IP address in the "SMTP Server"
9. Enter or change the SMTP port number in the "SMTP Port" field.
10. Click "OK."
11. Click "apply changes."
BLACK BOX® CS Installation, Administration, and User's Guide
from the pull-down menu. If desired, enable "Notification Alarm for Data
Buffering" for an alarm to sound when the trigger action occurs; and click
either "Add" or "Edit".
The "Notifications Entry" dialog box appears.
field.
list and proceed.
field.
Definition
The first time you specify an alarm trigger
the pull-down menu is empty. A new trigger
gets listed in the menu after it is created.
The email for the designated recipient of the
alarm notification.
The IP address of the SMTP server.
The port used by the SMTP server.
299
