Black Box Advanced Console Server User Manual page 59

R Item
3.
4.
5.
6.
7.
8.
BLACK BOX® CS Installation, Administration, and User's Guide
Description
Power cable.
RJ45 to DB25F
crossover adapter
RJ45 to DB25M
crossover adapter
RJ45 to DB9F
crossover adapter
Sun/Netra crossover
adapter
RJ45 to RJ45 7ft.
CAT5 cable
Purpose
To connect the CS to a power source.
To connect the console port to a computer
that has a DB-25 male connector.
To connect the console port to a computer
that has a DB-25 female connector.
To connect the console port to a computer
that has a DB-9 connector.
To connect the console port to a Sun Netra
server, or other devices with the same
pinout configuration.
Use for the following:
• To connect a device or an IPDU to a
serial port.
• To connect an Ethernet port to the LAN.
• To connect a terminal to a console port.
Shipping Box Contents
29
