Introduction
•
•
•
Figure 1-4: IPDU Integration With CS

Configuring Power Management

Administrators commonly perform power management through the Web
Manager, to assign power management permissions to users, configure IPMI
devices, and configure ports for power management.
24
commands. Authorized users can also perform IPMI power management
of serially-connected devices. The CS uses IPMI V1.5.
Remote power management of devices that are plugged into an IPDU that
is connected to CS
The intelligent power distribution unit (IPDU) can be an AlterPath PM
connected to any serial port. Up to 128 IPDU outlets can be daisy-
chained.
The diagram below shows a typical setup of the CS and an AlterPath PM
unit.
