The following table provides links to description and procedures for the forms
of the IPDU Power Mgmt. tabs.

Outlets Manager

View IPDUs Info
Users Manager
Configuration
Software Upgrade [for AlterPath PM]
Outlets Manager
On the "Outlets Manager" form under Applications>IPDU Power Mgmt., you
can do the following tasks for all outlets on all connected IPDUs.
•
•
•
•
•
•
•
•
The following figure shows an Outlets Manager form.
BLACK BOX® CS Installation, Administration, and User's Guide
Check the status of outlets
Turn outlets on and off
Cycle (Briefly switching the outlet off and on)
Lock outlets in the on or off state to prevent accidental changes
Unlock the outlets
Assign an alias to the outlet (to identify the device for which it provides
power)
Change the power up interval. The power up interval is the time interval
(in seconds) that the system waits between turning on the currently-
selected outlet and the next outlet.
Save the current configuration to Flash memory.
Applications
Page 121
Page 124
Page 127
Page 129
Page 131
121
