Network Menu & Forms
Figure 8-5: Expert > PCMCIA Modem Card Configuration Dialog Box
The following table provides a brief description of the fields available in the
Modem dialog box.
Table 8-3: Expert > Form Fields for a Modem Card
Field Name
[PCMCIA Card]
PPP
Local IP
Remote IP
Call Back
Phone Number
If you click the PPP checkbox, additional fields for a local and remote IP
address and a "Call Back" checkbox appear, as shown in the following figure.
162
Definition
Pull-down menu to select the type of PCMCIA
card that you are using.
Check box to enable point-to-point protocol.
The local IP address of the PCMCIA card.
The remote IP address of the PCMCIA card.
Check box to enable the callback security feature.
The phone number that the CS uses to call back.
