Figure 10-1: Expert > Ports - Black Box Advanced Console Server User Manual

Ports Menu & Forms
Menu Selection
Ports Statistics
The Ports section of CS configuration in Expert Mode provides the following
menu choices:
• Physical Ports – Allows you to view and modify the physical port settings.
• Virtual Ports – Allows you to view and modify the slave port settings.
• Ports Status – Allows you to view ports connection status.
•
Selecting Ports in Expert mode brings up the form shown in the following
figure.
Figure 10-1: Expert > Ports
238
Use this menu to:
View information on the data
reception (Rx bytes) and
transmission (Tx bytes) on each
physical port. View current CAS
user(s), Baud rate, frame, parity,
break, and overruns.
Ports Statistics – Allows you to view serial ports connection statistics.
Where Documented
Page 288
