Table 6-5: Expert > Ports
Menu Selection
Virtual Ports
Port Status
Ports Statistics

Table 6-6: Administration

Menu Selection
System Information
Notifications
BLACK BOX® CS Installation, Administration, and User's Guide
Use this menu to:
Perform Clustering. One CS can be
used as a Master to control other CS
(slaves) units. All ports of the slave
unit appear as if they are in the
master unit. This section shows how
to define and configure the slaves.
View the current status of each port.
The information provided here are:
RS232 Signal Status and user
connected to each port.
View information on the data
reception Rx bytes and transmission
Tx bytes on each physical port. View
current CAS user(s), Baud rate,
frame, parity, break and overruns.
Use this menu to:
information on the system
View
hardware, version, file system
and PCMCIA cards loaded
Configure the alarm strings and the
destination of the notification. CS
can send notification by email,
pager or SNMP trap in the
occurrence of any system warnings
and alarms.
Description of Forms in Expert Mode
Where Documented
Chapter 10, Page 281
Chapter 10, Page 287
Chapter 10, Page 288
Where Documented
Chapter 11, Page 292
Chapter 11, Page 295
111
