Installation and Configuration
2. Bring up a browser on the computer whose address you changed, enter the

Installing PCMCIA Cards

The front panel of the CS has two PCMCIA card slots as shown in the
following figure. You can insert and configure one card in each of the slots.
See Appendix C, "Supported PCMCIA Cards".

Figure 2-3: Front Panel PCMCIA Card Slots

To Install a PCMCIA Card

1. Insert the PCMCIA card into slot 1 or slot 2.
2. Use the Web Manager to configure the PCMCIA card.
Note: A hard disk PCMCIA card is automatically mounted once it is inserted, and it
needs no configuration.

To Remove a PCMCIA Card

Caution: Always use the Web Manager to eject a PCMCIA card. Any other method
may cause a kernel panic.
1. Eject the card by using the Eject button on the Web Manager's PCMCIA
46
CS's default IP address, http://192.168.160.10 to bring up the
Web Manager, and log in.
Management form, Expert > Network > PCMCIA Management > Eject
PCMCIA Slots
