To Configure Host Settings [Expert] - Black Box Advanced Console Server User Manual

Table 8-2: Expert > Host Settings Form Fields
Filed Name
Bonding
Caution: If you have set IP Filtering rules before bonding is activated, the interface
reference in the firewall configuration will be eth0. You need to change the
interface to bond0 in order to reference the bonded interface. See BLACK
BOX® CS Installation, Administration, and User's Guide, Chapter 3.

To Configure Host Settings [Expert]

1. Go to Network > Host Settings.
2. By default, the DHCP is enabled. To disable DHCP, click the checkbox to
3. Enter the name assigned to the IP address of the CS in the "Host Name"
4. Enter a console banner in the "Console Banner" field.
BLACK BOX® CS Installation, Administration, and User's Guide
The Host Settings form appears.
remove the check mark.
Additional fields appear.
field.
Field Definition
Enables redundancy for the Ethernet
devices using the standard Ethernet
interface as the primary mode of access and
a PCMCIA card as a secondary mode of
access.
If bonding is enabled, the following values
should be set.
Miimon: The interval in which the active
interface is checked to see if it is still
communicating (in milliseconds).
Updelay: The time that the system will
wait to make the primary interface active
after it has been detected as up (in
milliseconds).
Network
155
