LOG Target
If you select "LOG" from the "Target" field, the fields and menus shown in
the following figure appear in the "LOG Options Section" at the bottom of the
form.
Figure 8-36:Firewall Configuration "Add Rule" and "Edit Rule" LOG
The following table defines the menu options and fields in the "LOG Options
Section."
Table 8-16: Expert > Target LOG Options Selection Fields
Field or Menu Name
Log Level
Log Prefix
TCP Sequence
TCP Options
IP Options
BLACK BOX® CS Installation, Administration, and User's Guide
Target Fields
Definition
One of the options in the pull-down menu:
The prefix is included in the log entry.
Includes the TCP sequence in the log.
Includes TCP options in the log.
Includes IP options in the log.
Network
197
