Network Menu & Forms

Configuring a CDMA PCMCIA Card

You can use the "PCMCIA Management" form under "Network" to configure
a CDMA PCMCIA card. When you select "CDMA" from the pull-down
menu, the dialog box shown in the following figure appears.
Figure 8-14: Expert > PCMCIA CDMA Card Configuration Dialog Box
CDMA cards are modem cards that makes it possible for CS to receive a dial-
in connection and support callback feature using the "ppp" protocol.
The following table provides a brief description of the fields available in the
CDMA dialog box.
Table 8-9: Expert > Form Fields for a CDMA Card.
Field Name
[PCMCIA Card]
Local IP
Remote IP
174
Definition
Pull-down box to select the type of PCMCIA
card that you are using.
The local IP address of the CDMA card used
by the ppp connection.
The remote IP address of the CDMA card used
by the ppp connection.
