Add Rule and Edit Rule Options

When you add or edit a rule you can define any of the options described in the
following table.

Table 1-3: Filter Options for Packet Filtering Rules

Filter Options
Source IP and Mask
Destination IP and Mask
Protocol
Input Interface
Output Interface
Fragments
You can flag any of the above elements with inverted so that the target action
is performed on packets that do not match any of the criteria specified in that
line. For example, if you select DROP as the target action, specify "Inverted"
for a source IP address, and do not specify any other criteria in the rule, any
BLACK BOX® CS Installation, Administration, and User's Guide
Description
If you specify a source IP, incoming packets are filtered for
the specified IP address. If you specify a destination IP,
outgoing packets are filtered for the specified IP address.
If you fill in a source or destination mask, incoming or
outgoing packets are filtered for IP addresses from the
subnetwork in the specified netmask.
You can select a protocol for filtering from one of the
following options:
• ALL
• Numeric Protocol Options
• TCP Protocol Options
• UDP Protocol Options
• ICMP Protocol Options
The input interface (ethN) used by the incoming packet.
The output interface (ethN) used by the outgoing packet.
The types of packets to be filtered:
• All packets
• 2nd, 3rd... fragmented packets
• Non-fragmented and 1st fragmented packets
Packet Filtering on CS
