Table 11-10: Expert > Upgrade Firmware Form Fields; Figure 11-11: Expert > Administration > Upgrade Firmware - Black Box Advanced Console Server User Manual

Administration Menu & Forms
Figure 11-11: Expert > Administration > Upgrade Firmware
You can use this form to configure an automated upgrade of the CS's
firmware which includes the Kernel, applications, and configuration files. The
firmware is upgradeable using an FTP server. You can upgrade the firmware
directly through BLACK BOX®' FTP site at
Term-Servers/, or download the new firmware to a local FTP server and
upgrade from there.
Note: Check the file name for the upgrade version and read the upgrade instructions
carefully. Distinct procedures are required depending on the version you are
upgrading from.
The following table describes the fields in the "Upgrade Firmware" form.
Table 11-10: Expert > Upgrade Firmware Form Fields
Field/Menu Definition
Name
FTP is the only supported type.
Type
314
ftp://ftp.blackbox.com/lan/
