Applications Menu & Forms
When a user is added, their name is added to the list on the Users Manager
form, as shown in the following figure.

To Configure Users to Manage Power Outlets on IPDUs

1. Go to Applications > IPDU Power Mgmt. > Users Manager.
2. To disable a user's ability to manage power, select the username from the
3. To edit a user, select the username from the Users Information list and
4. To add a new user, click "Add."
5. In the "Add/Edit User x Outlets" dialog box, do the following as
6. Click OK.
7. Click "apply changes."
128
The "Users Manager" form appears.
Users Information list and then click "Delete."
then click "Edit."
The "Add/Edit User x Outlets" dialog box appears.
The "Add/Edit User x Outlets" dialog box appears.
appropriate.
a. Enter the username in the "User" field.
b. Enter or modify the numbers of the outlets to which the user is
assigned in the "Outlets" field.
Use a comma to separate outlet numbers, and use a hyphen to indicate
a range of outlets (for example: 1, 3, 4, 6-8).
The Users Information list displays the changes.
