Applications Menu & Forms
To Lock or Unlock a Group of Outlets in the Same Power
State
Use these instructions if all of the outlets in a group are either locked or
unlocked.
1. Go to Applications > IPDU Multi-Outlet Ctrl.
2. To lock the group of outlets, click the open padlock icon adjacent to the
3. To unlock the group of outlets, click the closed padlock icon adjacent to
To Lock or Unlock a Group of Outlets in Different Lock
States
Use these instructions if not all of the outlets in a group are locked or
unlocked.
1. Go to Applications > IPDU Multi-Outlet Ctrl.
2. To lock the group of outlets, do the following steps:
3. To unlock the group of outlets, click the closed padlock icon adjacent to

To Turn the Power of a Group of Outlets Off and On Again

This procedure works only with groups of outlets that are all turned on.
138
a. Click the yellow light bulb icon adjacent to the group name once to
turn all of the outlets off.
All of the outlets are in the same state.
b. To turn all of the outlets on, click the grey light bulb icon adjacent to
the group name.
group name.
the group name.
a. Click the open padlock icon adjacent to the group name once to
unlock all of the outlets.
All of the outlets are in the same state (open padlock).
b. To lock all of the outlets, click the open padlock icon adjacent to the
group name.
the group name.
