Figure 8-4: Expert > Network > PCMCIA Management
You can use the PCMCIA management form to configure the following types
of PCMCIA cards. For a list of the s
•
•
•
•
•
•
•
•
Note: You can insert a card at any time and the corresponding driver should load
automatically. Before removing a card, however, you must use the Web
Manager to eject the card and stop the system from using the card. If you
install an IDE PCMCIA card in a slot, it automatically mounts and no
configuration is necessary through this form.
Note: CS supports GPRS and 1xRTT PCMCIA cards through a Generic Dial-Out
application. For Configuration details refer to the CS Command Reference
Guide, Chapter 7, Section 7.3 "Generic Dial-Out".
BLACK BOX® CS Installation, Administration, and User's Guide
10/100 Base-T Ethernet
802.11b Wireless LAN
V.90 Modem
ISDN
GSM
CDMA
Compact Flash
IDE Hard Disk
upported PCMCIA cards see Appendix C.
Network
