Note: Only one outlet needs to be powered on or unlocked in order for the entire
group to be considered on or unlocked. In this case, it takes two clicks to turn
the power off or to lock the entire group instead of the one click. (one click is
sufficient when all of the outlets are in the same state). The first click turns the
other outlets on or unlocks them so that all the outlets are in the same state; the
second click turns all of the outlets off or locks them.
The Cycle button operates only if all outlets of a group are turned on.
Note: The "power up interval" parameter configured for each outlet plays an
important role in the power up sequence of multi-outlet devices because the
next outlet in the group turns on only after the power up interval specified for
the current outlet has elapsed. To configure this parameter go to Applications
> IPDU Power Mgmt > Outlets Manager > Edit.
To Power On or Power Off a Group of Outlets in the Same
Power State
Use these instructions if all of the outlets in a group are turned either off or on.
1. Go to Applications > IPDU Multi-Outlet Ctrl.
2. To power on the group of outlets in OFF state, click the grey light bulb
3. To power off the group of outlets in ON, click the yellow light bulb
To Power On or Power Off a Group of Outlets in Different
Power States
Use these instructions if not all of the outlets in a group are turned either off or
on.
1. Go to Applications > IPDU Multi-Outlet Ctrl.
2. To power on the group, click the yellow light bulb adjacent to the group
3. To power off the group, do the following steps:
BLACK BOX® CS Installation, Administration, and User's Guide
adjacent to the group name.
adjacent to the group name.
name.
All of the outlets turns on.
Applications
137
