Black Box Advanced Console Server User Manual page 215

3. To edit any SNMP configuration, do the following steps.
4. For SNMP v1 or v2 configuration, enter or change the following
5. For SNMP v3 configuration, enter or change the following information:
Note: The SNMPv3 password must be less than 31 characters.
6. For any version of SNMP, do the following steps.
7. Click OK.
8. Click "apply changes"
Note: In addition to SNMP configuration described in this section, you need to make
sure SNMP service is enabled and configured for one or more serial ports in
order to send SNMP traps. The related tasks are listed in the following table.
BLACK BOX® CS Installation, Administration, and User's Guide
The "New/Modify SNMP Daemon Configuration" dialog box appears.
a. To edit an SNMPv1/SNMPv2 entry, select the entry from the
"SNMPv1/SNMPv2 Configuration" list and click the "Edit" button.
b. To edit an SNMPv3 entry, select an entry from the "SNMPv3
Configuration" list and click the "Edit" button.
The "New/Modify SNMP Daemon Configuration" dialog box appears.
information:
a. Enter the community name in the "Community" field.
b. Enter the source IP address or range of IP addresses in the "Source"
field.
a. Enter the user name in the "User name" field.
b. Enter the password in the "Password" field.
a. Enter the unique object identifier for the object in the "OID" field.
b. Choose "Read Only" or "Read/Write" from the "Permission" field.
Network
185
