Table 9-7: Expert > Enabled Protocols For Each Security Profile Shown With A Check Mark - Black Box Advanced Console Server User Manual

Table 9-7: Expert > Enabled protocols for each security profile shown with a check mark.
Other Services
SNMP
RPC
ICMP
FTP
IPSec
1-The Default security profile parameters is the same as Moderate profile.
The first step in configuring your Advanced Console Server is to define a
Security Profile. One of the following situations is applicable when you boot
up the CS unit.
1. CS is starting for the first time, or after a reset to factory default
2. CS firmware is upgraded and the system is restarting with the new
3. CS is restarting normally.
BLACK BOX® CS Installation, Administration, and User's Guide
Secure
parameters.
In this situation when you boot CS up and login as an administrator to the
Web Manager, a security warning dialog box appears. The Web Manager
is redirected to "Step1: Security Profile" in the Wizard mode. Further
navigation to other sections of the Web Manager is not possible without
selecting or configuring a Security Profile. Once you select or configure a
Security Profile and save the changes CS restarts.
firmware.
In this situation the CS was already in use and certain configuration
parameters were saved in the flash memory. In this case CS automatically
retrieves the "Custom Security Profile" parameters saved in the flash
memory and behaves as it was a normal reboot.
In this situation the system detects the pre-defined security profile. You
can continue working in the Web Manager.
Moderate Open 1 Custom
Default
229
