Multi User - Black Box Advanced Console Server User Manual

Ports Menu & Forms
4. If you checked "Buffer to Syslog," perform the following steps.
Note: Obtain the facility number from the system administrator of the syslog server.
Options range from Local0 to Local7.
5. Click "Done."
6. Click "apply changes."
To configure alarm notifications to be sent based on the type of buffered data,
use the Notifications form, Expert > Administration > Notifications.

Multi User

Under Ports > Physical Ports in Expert Mode, after you select one or more
serial ports, and click the Modify Port(s), you can select the Multi User form
from the tabbed menu. The following form appears.
268
• Show data buffering file only
• Show without the erase options
a. Enter the IP address of the syslog server in the "Syslog Server" field.
b. Choose an option from the "Facility Number" pull-down menu.
c. Enter the maximum size of the buffer in the "Syslog Buffer Size"
field.
d. Click the radio button next to one of the following options:
• Buffer Syslog at all times
• Buffer only when nobody is connected to the port
