Network Menu & Forms
Field Name
Network Address

To Configure an Ethernet PCMCIA Card

1. Install the Ethernet card and select "Ethernet" from the pull-down menu
2. In the "IP address" field, enter the IP address to assign to the Ethernet
3. In the "Network Mask" field, enter the netmask to assign to the subnet.
4. Click OK.
5. Click "apply changes.
Configuring a PCMCIA Compact Flash Card or a PCMCIA Hard
Disk Drive
You can use the "PCMCIA Management" form under "Network" to configure
a PCMCIA Compact Flash card or a PCMCIA Hard Disk Drive. When you
select Compact Flash/Hard Disk from the pull-down menu, the dialog box
shown in the following figure appears.
170
on the PCMCIA Management form.
The "IP Address" and "Network Mask" fields appear on the Slot dialog
box.
port.
Definition
The network address of the Ethernet.
