Table 11-7: Expert > Boot Configuration Form Fields
Field Name
Fast Ethernet Max.
Interrupt Events

To Configure CS Boot

1. Go to Administration > Boot Configuration in Expert mode.
2. Enter the IP address of the CS in the "IP Address assigned to Ethernet"
3. Accept or change the selected option in the "Watchdog Timer" field.
4. Select to boot from "Flash" or "Network" from the "Unit boot from"
5. Select "TFTP", "BOOTP", or "Both" from the "Boot Type" menu if you
6. Accept or change the filename of the boot program in the "Boot File
7. If specifying network boot, do the following steps.
BLACK BOX® CS Installation, Administration, and User's Guide
The Boot Configuration form appears.
field.
menu.
have selected "Network" from the "Unit boot from" in step 4.
Name" field.
a. Enter the IP address of the TFTP, or BOOTP server in the "Server's
IP Address" field.
b. Select a console speed from the "Console Speed" pull-down menu to
match the speed of the terminal you are using on the console port of
the CS.
c. Select "Skip" or "Full" from the "Flash Test" pull-down menu to
bypass or run a test on the flash memory at boot time.
d. Select "Skip", "Quick", or "Full" from the "RAM Test" pull-down
menu to bypass or run a test on the RAM at boot time.
e. Choose an Ethernet speed from the "Fast Ethernet" pull-down menu.
f. Specify the maximum number of packets that the CPU handles before
an interrupt in the "Fast Ethernet Max. Interrupt Events" field.
Definition
The maximum number of packets that the
CPU handles before an interrupt (0 is the
default).
