Table 8-8: Expert > Form Fields for a Wireless LAN Card.
Field Name
[PCMCIA Card]
IP Address
Network Mask
MyPrivateNet
(ESSID)
Channel
Encrypted
Key

To Configure a Wireless LAN PCMCIA Card

1. Install the wireless LAN card and select "Wireless LAN" from the pull-
2. In the "IP address" field, enter an IP address.
3. In the "Network Mask" field, enter the netmask for the subnet.
4. In the "MyPrivateNet (ESSID)" field, enter the SSID for communicating
5. In the "Channel" field, enter a channel number.
6. Click the "Encrypted" checkbox, if an encrypted data communication is
7. Enter a unique key for decoding the encrypted data.
8. Click OK.
9. Click "apply changes."
BLACK BOX® CS Installation, Administration, and User's Guide
down menu on the PCMCIA Management form.
with others in your network.
required.
Definition
Pull-down box to select the type of PCMCIA
card that you are using.
The local IP address of the Ethernet.
The network address of the Ethernet.
The unique identifier for the wireless access
point.
The communication channel with the access
point.
The translation of data into code during
transmission.
The key or password to decode the encrypted
data.
Network
173
