Network Menu & Forms
Table 8-12: Expert > Tasks for Configuring SNMP
Task
To configure one or more serial
ports to send SNMP traps.

Firewall Configuration

Firewall configuration, also known as IP filtering, refers to the selective
blocking of the passage of IP packets between global and local networks. The
filtering is based on rules that describe the characteristics of the packet. For
example, the contents of the IP header, the input/output interface, or the
protocol.
This feature is used mainly in firewall applications to filter the packets that
could potentially harm the network system or generate unnecessary traffic in
the network.
Selecting Network > Firewall Configuration brings up the form shown in the
following figure.
Figure 8-20: Expert > Network > Firewall Configuration
You can use the Firewall Configuration form to enable firewall on CS. You
can define rules to allow or disallow packets, and configure filtering of
packets that are sent and received through CS.
Packet filtering relies on defined chains and rules. See "Packet Filtering on
CS" on page 13 for details.
186
Where Documented
See "SNMP Trap Notifications Entry" on page 302
