Figure 8-8: Expert > ISDN PCMCIA Card Configuration Dialog Box
The following table provides a brief description of the fields available in the
ISDN dialog box.
Table 8-4: Expert > Form Fields for an ISDN Card
Field Name
[PCMCIA Card]
Local IP
Remote IP
Call Back
Phone Number

To Configure an ISDN PCMCIA Card

1. Install the ISDN card and select "ISDN" from the pull-down menu on the
BLACK BOX® CS Installation, Administration, and User's Guide
PCMCIA Management form.
The "Local IP" and "Remote IP" fields and the "Call Back" check box
appear on the Slot dialog box.
Definition
Select ISDN from the pull-down menu.
The local IP address of the PCMCIA card.
The remote IP address of the PCMCIA card.
Check box to enable the callback security
feature.
The phone number that CS uses to call back.
Network
