Chapter 10 Obtaining and Installing Licenses
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
Click the Features tab to see the name of the feature package, the type of license, the expiration date,
Step 2
the grace period (if you do not have a license for a particular feature), and any errors, such as a missing
license.
Click the Files tab to display the information about each of the License Key files installed on your
Step 3
switch.
Click the Install tab to install or update a license file.
Step 4
Click the Usage tab to which applications are using the features on the switch.
Step 5

Viewing Licenses Using Fabric Manager Web Server

Fabric Manager Release 2.1(2) or later supports viewing license use across the fabric from Fabric
Manager Web Server. This view summarizes the licenses used on all switches in the fabric.
To view licenses using Fabric Manager Web Server, choose Inventory > Licenses.

Fabric Manager Server Licensing

When you install Fabric Manager, the basic version of the Fabric Manager Server (FMServer) is installed
with it. To get the enhanced features, such as Performance Manager and remote client support you will
need to buy and install the Cisco MDS 9000 Family Fabric Manager Server license package.
However, trial use of these enhanced features is available. To enable the 120-day trial, you simply use
the feature as you would if you had purchased the license. You see a dialog box explaining that this is a
demo version, enabled for a limited time.
If you are evaluating Fabric Manager Server features and want to stop the evaluation period for that
feature, you can do that using Device Manager.
To stop the evaluation using Device Manager, follow these steps:
Step 1 Select Admin > Licenses.
You see the Licenses dialog box.
Step 2 Click the Features tab and select the feature to check in.
When you select the feature, you see a Check In FM button at the bottom of the dialog box.
Click Check In FM to stop the demo period timer.
Step 3
OL-17256-03, Cisco MDS NX-OS Release 4.x
Cisco MDS 9000 Family Fabric Manager Configuration Guide
Fabric Manager Server Licensing
10-17
