height-adjustable bench
Section:
METAL GABLES & CABLE CHANNEL
Optional: If Mid Power Pole is specified. Please fasten Connecting Bracket to the underside of the Stretcher Bars as shown.
NOTE: Please refer to installation guide HABN_322b
MID POWER POLE SUPPORT PLATE (OPTIONAL)
NOTE: Cable Channels are Hidden for Illustration Purpose.
Installation Guides
Date: Feb 2022
Page: 9 of 18
HABN_223a
