height-adjustable bench
Installation Guides
Date: Feb 2022
Page: 13 of 18
Section:
METAL GABLES & CABLE CHANNEL
HABN_223a
ATTACH SUPPORT BRACKET
MOUNT SIDE COVER ASSEMBLY
3.3
1.4
STEP 13: Insert Support Bracket through the cut-out on the Side Cover Assembly
STEP 14: Mount Side Cover Assembly onto the Stretcher Bar as shown
