Teknion Navigate height-adjustable bench Manual page 92

height-adjustable bench
Section: METAL GABLES & CABLE CHANNEL
ITEM
PREVIEW
NO.
2. NAVIGATE END GABLE - METAL (HNBCGEMN) X2
2.1
2.2
2.3
2.4
Part & Product Identification
PART
DESCRIPTION
NUMBER
INSIDE COVER
ASSY FOR METAL
N09-8810-
END GABLE
DOUBLE SIDED,
HAB
INSIDE COVER FOR
METAL END GABLE A16-7473-
DOUBLE SIDED,
HAB
GABLE
CONNECTING A16-3651
PLATE
#10X1/2" TAP SCR
E01-0023
QUAD PAN
Installation Guides
ITEM
QTY
PREVIEW
NO.
3. NAVIGATE MID GABLE - METAL (HNBCGMMN) X1
3.1
1
X
3.2
1
X
3.3
3.4
2
3.5
2
Date: Feb 2022
HABN_223a
PART
DESCRIPTION
NUMBER
TOP COVER FOR
A16-3085
METAL MID GABLE
W/ POWER POLE,
A16-3086
HAB
SIDE COVER ASSY
W/ CABLE &
N09-5183-
BASEFEED CUTOUT
FOR METAL MID
GABLE, HAB
SIDE COVER ASSY
W/ CABLE CUTOUT N09-5185-
FOR METAL MID
GABLE, HAB
FRONT COVER
ASSY FOR METAL N09-5182
MID GABLE, HAB
TOP COVER FOR
METAL MID GABLE
A16-3025
W/ POWER POLE,
HAB (OPTIONAL)
Page: 3 of 18
QTY
& 1
1
X
1
X
2
2
